optimizeConfigurationForNetwork

Class: dlhdl.ProcessorConfig
Package: dlhdl

Retrieve optimized network-specific deep learning processor configuration

Syntax

optimizeConfigurationForNetwork(network)

Description

optimizeConfigurationForNetwork(network) returns an optimized deep learning processor configuration for the object specified by the network argument.

Input Arguments

expand all

Name of network object for optimized deep learning processor configuration, specified as a SeriesNetwork, DAGNetwork, yolov2ObjectDetector, or dlquantizer object.

Example: optimizeConfigurationForNetwork(snet)

Examples

expand all

  1. Create a dlhdl.ProcessorConfig object.

    net = mobilenetv2;
    hPC = dlhdl.ProcessorConfig;
  2. To retrieve an optimized processor configuration, call the optimizeConfigurationForNetwork method.

    hPC.optimizeConfigurationForNetwork(net)
    ### Optimizing processor configuration for deep learning network begin.
    ### Optimizing series network: Fused 'nnet.cnn.layer.BatchNormalizationLayer' into 'nnet.cnn.layer.Convolution2DLayer'
    ### Note: Processing module "conv" property "InputMemorySize" changed from "[227 227 3]" to "[224 224 3]".
    ### Note: Processing module "conv" property "OutputMemorySize" changed from "[227 227 3]" to "[112 112 32]".
    ### Note: Processing module "conv" property "FeatureSizeLimit" changed from "2048" to "1280".
    ### Note: Processing module "conv" property "LRNBlockGeneration" changed from "on" to "off" because there is no LRN layer in the deep learning network.
    ### Note: Processing module "fc" property "InputMemorySize" changed from "25088" to "1280".
    ### Note: Processing module "fc" property "OutputMemorySize" changed from "4096" to "1000".

                        Processing Module "conv"
                                ModuleGeneration: 'on'
                              LRNBlockGeneration: 'off'
                                ConvThreadNumber: 16
                                 InputMemorySize: [224 224 3]
                                OutputMemorySize: [112 112 32]
                                FeatureSizeLimit: 1280

                          Processing Module "fc"
                                ModuleGeneration: 'on'
                          SoftmaxBlockGeneration: 'off'
                                  FCThreadNumber: 4
                                 InputMemorySize: 1280
                                OutputMemorySize: 1000

                       Processing Module "adder"
                                ModuleGeneration: 'on'
                                 InputMemorySize: 40
                                OutputMemorySize: 40

                  Processor Top Level Properties
                                  RunTimeControl: 'register'
                              InputDataInterface: 'External Memory'
                             OutputDataInterface: 'External Memory'
                               ProcessorDataType: 'single'

                         System Level Properties
                                  TargetPlatform: 'Xilinx Zynq UltraScale+ MPSoC ZCU102 Evaluation Kit'
                                 TargetFrequency: 200
                                   SynthesisTool: 'Xilinx Vivado'
                                 ReferenceDesign: 'AXI-Stream DDR Memory Access : 3-AXIM'
                         SynthesisToolChipFamily: 'Zynq UltraScale+'
                         SynthesisToolDeviceName: 'xczu9eg-ffvb1156-2-e'
                        SynthesisToolPackageName: ''
                         SynthesisToolSpeedValue: ''

    ### Optimizing processor configuration for deep learning network complete.
Introduced in R2021b
