Matching Network Design

Design narrowband matching networks

Matching network designs a set of circuits that match the impedance of a given source to the impedance of a give load at a specified center frequency.

Apps

Matching Network DesignerDesign, visualize, and compare matching networks for one-port load (Since R2021a)

Objects

matchingnetworkCreate matching network for 1-port network and generate circuit object (Since R2019a)

Functions

addEvaluationParameterAdds performance goal for sort, pass, or fail matching network design (Since R2019a)
circuitDescriptionsTables describing each created matching network's topology and performance (Since R2019a)
getEvaluationParametersTable of evaluation parameters currently used to rank and pass or fail matching network designs (Since R2019a)
clearEvaluationParameterDelete one or more performance goals (Since R2019a)
exportCircuitsSelect and export generated matching networks as circuit objects from an existing matching network object (Since R2019a)
rfplotPlot input reflection coefficient and transducer gain of matching network (Since R2019a)
smithplotPlot impedance transformation for selected matching network on smith chart (Since R2019a)
sparametersCalculate S-parameters for RF data, network, circuit, and matching network objects
