Test and Measurement
LTE Toolbox™ provides functions that let you measure transmitter performance characteristics. The examples featured here demonstrate transmitter modeling and performance analysis. Communications Toolbox™ and DSP System Toolbox™ System objects provide additional quantitative tools for measuring system performance, and graphical utilities for visualizing waveforms.
|Waveform From Wireless Waveform Generator App
|Wireless waveform source exported to Simulink (Since R2021b)
Measurement Channel Configuration
- Generate a Test Model
The LTE specifications define conformance test models for transmitter tests.
- Generate Wireless Waveform in Simulink Using App-Generated Block
This example shows how to configure and use the block that is generated using the Export to Simulink capability that is available in the Wireless Waveform Generator app.
