backtestStrategy

Create backtestStrategy object to define portfolio allocation strategy

Description

Create a backtestStrategy object which defines a portfolio allocation strategy.

Use this workflow to develop and run a backtest:

  1. Define the strategy logic using a backtestStrategy object to specify how the strategy rebalances a portfolio of assets.

  2. Use backtestEngine to create a backtestEngine object that specifies the parameters of the backtest.

  3. Use runBacktest to run the backtest against historical asset price data and, optionally, trading signal data.

  4. Use summary to summarize the backtest results in a table format.

For more detailed information on this workflow, see Backtest Investment Strategies.

Creation

Description

example

strategy = backtestStrategy(name,rebalanceFcn) creates a backtestStrategy object.

example

strategy = backtestStrategy(___,Name,Value) sets properties using name-value pair arguments and any of the arguments in the previous syntax. You can specify multiple name-value pair arguments. For example, strat = backtestStrategy('MyStrategy',@myRebalFcn,'TransactionCost',0.005,'LookbackWindow',20).

Input Arguments

expand all

Strategy name, specified as a string.

Data Types: string

Rebalance function, specified as a function handle. A function handle computes new portfolio weights during the backtest. The rebalanceFcn argument implements the core logic of the trading strategy and must have one of the following signatures:

  • new_weights = rebalanceFcn(weights,assetPrices)

  • new_weights = rebalanceFcn(weights,assetPrices,signalData)

The rebalance function is called by the backtestEngine object each time the strategy must be rebalanced. The backtestEngine object calls the rebalance function with the following arguments:

  • weights — The current portfolio weights before rebalancing, specified as decimal percentages.

  • assetPrices — A timetable containing a rolling window of adjusted asset prices.

  • signalData — A timetable containing a rolling window of signal data. If you provide signal data is to the backtestEngine object, then the engine object passes it to the strategy rebalance function using the three input argument syntax. If do not provide signal data the backtestEngine object, then the engine object calls the rebalance function with the two input argument syntax.

    The rebalance function must return a single output argument for new_weights which is a vector of asset weights specified as decimal percentages.

    • If the new_weights sum to 1, then the portfolio is fully invested.

    • If the new_weights sum to less than 1, then the portfolio will has the remainder in cash, earning the RiskFreeRate specified in the backtestEngine object.

    • If the new_weights sum to more than 1, then there is a negative cash position (margin) and the cash borrowed accrues interest at the cash borrowing rate specified in the CashBorrowRate property of the backtestEngine object.

    For more information on developing a rebalanceFcn function handle, see Backtest Investment Strategies.

Data Types: function_handle

Name-Value Pair Arguments

Specify optional comma-separated pairs of Name,Value arguments. Name is the argument name and Value is the corresponding value. Name must appear inside quotes. You can specify several name and value pair arguments in any order as Name1,Value1,...,NameN,ValueN.

Example: strat = backtestStrategy('MyStrategy',@myRebalFcn,'TransactionCost',0.005,'LookbackWindow',20)

Rebalance frequency during the backtest, specified as the comma-separated pair consisting of 'RebalanceFrequency' and a scalar numeric representing the number of time steps between rebalancing. For example, if you provide the backtestEngine object with daily price data, then the RebalanceFrequency specifies the number of days between rebalancing. The default is 1, meaning the strategy rebalances with each time step.

Data Types: double

Transaction costs for trades, specified as the comma-separated pair consisting of 'TransactionCosts' and a scalar numeric, vector, or function handle. You can specify transaction costs in three ways:

  • rate — A scalar decimal percentage charge to both purchases and sales of assets. For example ,if you set TransactionCosts to 0.001, then each transaction (buys and sells) would pay 0.1% in transaction fees.

  • [buyRate, sellRate] — A 1-by-2 vector of decimal percentage rates that specifies separate rates for buying and selling of assets.

  • computeTransactionCostsFcn — A function handle to compute customized transaction fees. If you specify a function handle, the backtestEngine object calls the TransactionCosts function to compute the fees for each rebalance. The user-defined function handle must have the following signature:

    [buyCosts,sellCosts] = computeCostsFcn(deltaPositions)

    The user-defined function handle takes a single input argument deltaPositions, which is a vector of changes in asset positions for all assets (in currency units) as a result of a rebalance. Positive elements in the deltaPositions vector indicate purchases while negative entries represent sales. The user-defined function handle must return two output arguments buyCosts and sellCosts, which contain the total costs (in currency) for the entire rebalance for each type of transaction.

Data Types: double | function_handle

Lookback window, specified as the comma-separated pair consisting of 'LookbackWindow' and a 1-by-2 vector that defines the minimum and maximum size of the rolling window of data (asset prices and signal data) that you provide to the rebalanceFcn argument. You specify these limits in terms of the number of time steps. For example, if the backtestEngine object is provided with daily price data, then LookbackWindow specifies the size bounds of the rolling window in days. The default is [0 Inf], meaning that all available past data is given to the rebalance function. If you specify a non-zero minimum, then the software does not call rebalanceFcn until enough time steps process to meet the minimum size.

If you specify LookbackWindow as a single scalar value, then the value is both the minimum and maximum of the LookbackWindow (that is, a fixed-sized window).

Data Types: double

Initial portfolio weights, specified as the comma-separated pair consisting of 'InitialWeights' and a vector. The InitialWeights vector sets the portfolio weights before the backtestEngine object begins the backtest. The size of the initial weights vector must match the number of assets used in the backtest.

Alternatively, you can set the InitialWeights name-value pair argument to empty ([ ]) to indicate the strategy will begin with no investments and in a 100% cash position. The default for InitialWeights is empty ([ ]).

Data Types: double

Properties

expand all

Strategy name, specified as a string.

Data Types: string

Rebalance function, specified as a function handle.

Data Types: function_handle

Rebalance frequency during the backtest, specified as a scalar numeric.

Data Types: double

Transaction costs, specified as a scalar numeric, vector, or function handle.

Data Types: double | function_handle

Lookback window, specified as a scalar numeric or vector.

Data Types: double

Initial weights, specified as a vector.

Data Types: double

Examples

collapse all

Define a backtest strategy by using a backtestStrategy object. backtestStrategy objects contain properties specific to a trading strategy, such as the rebalance frequency, transaction costs, and a rebalance function. The rebalance function implements the core logic of the strategy and is used by the backtesting engine during the backtest to allow the strategy to change its asset allocation and to make trades. In this example, to illustrate how to create and use backtest strategies in MATLAB®, you prepare two simple strategies for backtesting:

  1. An equal weighted strategy

  2. A strategy that attempts to "chase returns"

The strategy logic for these two strategies is defined in the rebalance functions.

Set Strategy Properties

A backtestStrategy object has several properties that you set using parameters for the backtestStrategy function.

Initial Weights

The InitialWeights property contains the asset allocation weights at the start of the backtest. The default value for InitialWeights is empty ([]), which indicates that the strategy begins the backtest uninvested, meaning that 100% of the capital is in cash earning the risk-free rate.

Set the InitialWeights to a specific asset allocation. The size of the initial weights vector must match the number of assets in the backtest.

% Initialize the strategies with 30 weights, since the backtest
% data comes from a year of the 30 DJIA stocks.
numAssets = 30;

% Give the initial weights for both strategies equal weighting. Weights
% must sum to 1 to be fully invested.
initialWeights = ones(1,numAssets);
initialWeights = initialWeights / sum(initialWeights);

Transaction Costs

The TransactionCosts property allows you to set the fees that the strategy pays for trading assets. Transaction costs are paid as a percentage of the total change in position for each asset. Specify costs in decimal percentages. For example, if TransactionCosts is set to 1% (0.01) and the strategy buys $100 worth of a stock, then the transaction costs incurred are $1.

Transaction costs are set using a 1-by-2 vector that sets separate fee rates for purchases and sales of assets. In this example, both strategies pay the same transaction costs — 25 basis points for asset purchases and 50 basis points for sales.

% Define the Transaction costs as [buyCosts sellCost] and specify the costs
% as decimal percentages.
tradingCosts = [0.0025 0.005];

You can also set the TransactionCosts property to a function handle if you need to implement arbitrarily complex transaction cost structures. For more information on creating transaction cost functions, see backtestStrategy.

Rebalance Frequency

The RebalanceFrequency property determines how often the backtesting engine rebalances and reallocates the portfolio of a strategy using the rebalance function. Set the RebalanceFrequency in terms of time steps in the backtest. For example, if the backtesting engine is testing a strategy with a set of daily price data, then set the rebalance function in days. Essentially, RebalanceFrequency represents the number of rows of price data to process between each call to the strategy rebalance function.

% Both strategies rebalance every 4 weeks (20 days).
rebalFreq = 20;

Lookback Window

Each time the backtesting engine calls a strategy rebalance function, a window of asset price data (and possibly signal data) is passed to the rebalance function. The rebalance function can then make trading and allocation decisions based on a rolling window of market data. The LookbackWindow property sets the size of these rolling windows. Set the window in terms of time steps. The window determines the number of rows of data from the asset price timetable that are passed to the rebalance function.

The LookbackWindow property can be set in two ways. For a fixed-sized rolling window of data (for example, "50 days of price history"), the LookbackWindow property is set to a single scalar value (N = 50). The software then calls the rebalance function with a price timetable containing exactly N rows of rolling price data.

Alternatively, you can define the LookbackWindow property by using a 1-by-2 vector [min max] that specifies the minimum and maximum size for an expanding window of data. In this way, you can set flexible window sizes. For example:

  • [10 Inf] — At least 10 rows of data

  • [0 50] — No more than 50 rows of data

  • [0 Inf] — All available data (that is, no minimum, no maximum); this is the default value

  • [20 20] — Exactly 20 rows of data; this is equivalent to setting LookbackWindow to the scalar value 20

The software does not call the rebalance function if the data is insufficient to create a valid rolling window, regardless of the value of the RebalanceFrequency property.

If the strategy does not require any price or signal data history, then you can indicate that the rebalance function requires no data by setting the LookbackWindow property to 0.

% The equal weight strategy does not require any price history data.
ewLookback = 0;

% The "chase returns" strategy bases its decisions on the trailing
% 10-day asset returns. The lookback window is set to 11 since computing 10 days
% of returns requires the close price from day 0.
chaseLookback = 11;

Rebalance Function

The rebalance function (rebalanceFcn) is the user-authored function that contains the logic of the strategy. The backtesting engine calls the strategy rebalance function with a fixed set of parameters and expects it to return a vector of asset weights representing the new, desired portfolio allocation after a rebalance. For more information, see the rebalance functions.

Create Strategies

Using the prepared strategy properties, you can create the two strategy objects.

% Create the equal weighted strategy. The rebalance function @equalWeights
% is defined in the Rebalance Functions section at the end of this example.
equalWeightStrategy = backtestStrategy("EqualWeight",@equalWeight,...
    'RebalanceFrequency',rebalFreq,...
    'TransactionCosts',tradingCosts,...
    'LookbackWindow',ewLookback,...
    'InitialWeights',initialWeights)
equalWeightStrategy =
  backtestStrategy with properties:

                  Name: "EqualWeight"
          RebalanceFcn: @equalWeight
    RebalanceFrequency: 20
      TransactionCosts: [0.0025 0.0050]
        LookbackWindow: 0
        InitialWeights: [1x30 double]

% Create the "chase returns" strategy.  The rebalance function
% @chaseReturns is defined in the Rebalance Functions section at the end of this example.
chaseReturnsStrategy = backtestStrategy("ChaseReturns",@chaseReturns,...
    'RebalanceFrequency',rebalFreq,...
    'TransactionCosts',tradingCosts,...
    'LookbackWindow',chaseLookback,...
    'InitialWeights',initialWeights)
chaseReturnsStrategy =
  backtestStrategy with properties:

                  Name: "ChaseReturns"
          RebalanceFcn: @chaseReturns
    RebalanceFrequency: 20
      TransactionCosts: [0.0025 0.0050]
        LookbackWindow: 11
        InitialWeights: [1x30 double]

Set Up Backtesting Engine

To backtest the two strategies, use the backtestEngine object. The backtesting engine sets parameters of the backtest that apply to all strategies, such as the risk-free rate and initial portfolio value. For more information, see backtestEngine.

% Create an array of strategies for the backtestEngine.
strategies = [equalWeightStrategy chaseReturnsStrategy];

% Create backtesting engine to test both strategies.
backtester = backtestEngine(strategies);

Rebalance Functions

Strategy rebalance functions defined using the rebalanceFcn argument for backtestStrategy must adhere to a fixed API that the backtest engine expects when interacting with each strategy. Rebalance functions must implement one of the following two syntaxes:

function new_weights = exampleRebalanceFcn(current_weights,assetPriceTimeTable)

function new_weights = exampleRebalanceFcn(current_weights,assetPriceTimeTable,signalDataTimeTable)

All rebalance functions take as their first input argument the current allocation weights of the portfolio. current_weights represents the asset allocation just before the rebalance occurs. During a rebalance, you can use current_weights in a variety of ways. For example, you can use current_weights to determine how far the portfolio allocation has drifted from the target allocation or to size trades during the rebalance to limit turnover.

The second and third arguments of the rebalance function syntax are the rolling windows of asset prices and optional signal data. The two tables contain the trailing N rows of the asset and signal timetables that are passed to the runBacktest function, where N is set using the LookbackWindow property of each strategy.

If optional signal data is provided to the runBacktest function, then the backtest engine passes the rolling window of signal data to each strategy that supports it.

The equalWeight strategy simply invests equally across all assets.

function new_weights = equalWeight(current_weights,assetPrices) %#ok<INUSD>

% Invest equally across all assets.
num_assets = numel(current_weights);
new_weights = ones(1,num_assets) / num_assets;

end

The chaseReturns strategy invests only in the top X stocks based on their rolling returns in the lookback window. This naive strategy is used simply as an illustrative example.

function new_weights = chaseReturns(current_weights,assetPrices)

% Set number of stocks to invest in.
numStocks = 15;

% Compute rolling returns from lookback window.
rollingReturns = assetPrices{end,:} ./ assetPrices{1,:};

% Select the X best performing stocks over the lookback window
[~,idx] = sort(rollingReturns,'descend');
bestStocksIndex = idx(1:numStocks);

% Initialize new weights to all zeros.
new_weights = zeros(size(current_weights));

% Invest equally across the top performing stocks.
new_weights(bestStocksIndex) = 1;
new_weights = new_weights / sum(new_weights);

end
Introduced in R2020b
