# MagnetostaticResults

## Description

A `MagnetostaticResults`

object contains the
magnetic potential, magnetic field, magnetic flux density, and mesh values in a form
convenient for plotting and postprocessing.

The magnetic potential, magnetic field, and magnetic flux density are calculated at the
nodes of the triangular or tetrahedral mesh generated by `generateMesh`

. Magnetic potential values at the nodes appear in the
`MagneticPotential`

property. Magnetic field values at the nodes appear in
the `MagneticField`

property. Magnetic flux density values at the nodes
appear in the `MagneticFluxDensity`

property.

To interpolate the magnetic potential, magnetic field, and magnetic flux density to a
custom grid, such as the one specified by `meshgrid`

, use the `interpolateMagneticPotential`

, `interpolateMagneticField`

, and `interpolateMagneticFlux`

functions.

## Creation

Solve a magnetostatic problem using the `solve`

function. This function returns a solution as a `MagnetostaticResults`

object.

## Properties

## Object Functions

`generateMaxwellStressTensor` | Compute Maxwell stress tensor at nodal locations |

`interpolateMagneticPotential` | Interpolate magnetic potential in magnetostatic result at arbitrary spatial locations |

`interpolateMagneticField` | Interpolate magnetic field in magnetostatic result at arbitrary spatial locations |

`interpolateMagneticFlux` | Interpolate magnetic flux density in magnetostatic result at arbitrary spatial locations |

`interpolateMaxwellStressTensor` | Interpolate Maxwell stress tensor at arbitrary spatial locations |

## Examples

## Version History

**Introduced in R2021a**
