# designHalfbandIIR

Design and implement halfband IIR filter in the form of a coupled allpass filter

*Since R2023b*

## Syntax

## Description

`[`

designs a halfband IIR filter in the form of a coupled allpass filter with the filter
order of 17 by using the Butterworth design method. The function completes any
unspecified design parameters with appropriate default values.`a0`

,`a1`

] = designHalfbandIIR

`a0`

and `a1`

are the polynomial coefficients
of the two allpass filters *A _{0}*(z) and

*A*(z). These filters form the two branches of the coupled allpass filter. The transfer function of the IIR halfband filter is given by:

_{1}$$H(z)=0.5*[{A}_{0}({z}^{2})+{z}^{-1}{A}_{1}({z}^{2})],$$

The `designHalfbandIIR`

function implements the allpass filters in
the minimum multiplier form. For more information, see Algorithms.

The System object™ argument is `false`

by default. To implement the filter,
assign the filter coefficients in `a0`

, `a1`

to
one of the supported System objects.

`[`

specifies options using one or more name-value arguments.`a0`

,`a1`

] = designHalfbandIIR(`Name=Value`

)

For example, `[`

designs a halfband IIR filter with the filter order of 30 and transition width of 0.2 by
using the Elliptic window design method.`a0`

,`a1`

] =
`designHalfbandIIR`

(`FilterOrder`

=30,`TransitionWidth`

=0.2,`DesignMethod`

="ellip")

When you specify only a partial list of filter parameters, the function designs the filter by setting the other design parameters to their default values.

The function supports two design methods. Each design method supports a specific set
of design combinations. For more information, see `DesignMethod`

.

This function supports code generation under certain conditions. For more information, see Code Generation.

designs a halfband IIR filter and implements one of the supported System objects.`filtObj`

= designHalfbandIIR(`Name=Value`

)

This syntax applies when you set the `SystemObject`

argument to
`true`

.

## Examples

## Input Arguments

## Output Arguments

## Algorithms

The `designHalfbandIIR`

function models the IIR halfband filter in
the form of a coupled allpass filter using the minimum multiplier structure (single-rate
implementation) or in the form of an efficient polyphase structure (multirate
implementation).

The transfer function of the IIR halfband filter is

$$H(z)=0.5*[{A}_{0}({z}^{2})+{z}^{-1}{A}_{1}({z}^{2})],$$

The transfer function of *A _{0}*(z) and

*A*(z) in the elliptic form is

_{1}$${A}_{0}(z)={\displaystyle \prod _{k=1}^{N}\frac{{a}_{k}^{(0)}+{z}^{-1}}{1+{a}_{k}^{(0)}{z}^{-1}}}$$

and

$${A}_{1}(z)={\displaystyle \prod _{k=1}^{N}\frac{{a}_{k}^{(1)}+{z}^{-1}}{1+{a}_{k}^{(1)}{z}^{-1}}},$$

where *N* is the number of filter sections of the allpass filters
*A _{0}*(z) and

*A*(z).

_{1}**Single-Rate Filter Implementation**

When you set `Structure`

to `'single-rate'`

, the
`designHalfbandIIR`

function implements a coupled allpass filter
object comprising of a cascaded parallel structure of `dsp.AllpassFilter`

and `dsp.Delay`

filter objects.

This is a diagrammatic representation of the filter in the minimum multiplier form when
you set `Structure`

to `'single-rate'`

. The structure
of the coupled allpass filter is composed of two allpass filters
*A _{0}*(z) and

*A*(z) connected in parallel. The

_{1}`designHalfbandIIR`

function computes the overall filter output by
adding the output of the two respective branches. You can design the filters *A _{0}*(z) and

*A*(z) using the elliptic design method or the Butterworth design method.

_{1}**Multirate Filter Implementation**

When you set `Structure`

to `'interp'`

or
`'decim'`

, the function implements the filter using an efficient
two-branch polyphase structure. For more information on the polyphase implementation, see
the Algorithms section in the `dsp.IIRHalfbandInterpolator`

and `dsp.IIRHalfbandDecimator`

object pages.

## References

[1] Orfanidis , SJ. *High-Order Digital Parametric Equalizer Design*. 2005, pp.
1026–46.
