ADCToolbox

A toolbox for analyze and calibrate data from analog to digital converter (ADC) https://github.com/Arcadia-1/ADCToolbox.git

https://github.com/Arcadia-1/ADCToolbox.git

Download
Download

You are now following this Submission

Cite As

L. Jie and Z. Zhang. ADCToolbox (https://www.mathworks.com/matlabcentral/fileexchange/<...>), MATLAB Central File Exchange.

General Information

MATLAB Release Compatibility

  • Compatible with R2014b and later releases

Platform Compatibility

  • Windows
  • macOS
  • Linux
Version Published Release Notes Action
1.32.0

Adds xy presets for plotres/plotressin, improves plotspec noise-floor estimation for highly non-coherent signals, and allows column-vector weights in bitchk.

Download
1.31.0

Fix plotspec Nyquist bin handling

Download
1.30.0

Added two functions for visualizing partial-sum residuals of ADC bit matrices: plotres, plotressin

Download
1.21.0

- plotwgt: Added wgtsca and effres outputs
- adcpanel: Automatic maxCode calculation for bit-wise data
- wcalsin: Improve robustness under abnormal data

Download
1.20.0

- Add function 'adcpanel' for automatic one-stop ADC data analysis! More on 'help adcpanel'
- Add auto mode for 'sidebin' option in plotspec

Download
1.10.0

- Fixed some naming problems
- Add a new function 'plotwgt' to display the weighting of ADC code
- Improve display quality for 'errsin'
- Add an auto mode (now default) for calculating noise floor in 'plotspec'

Download
1.1.0

Rename specplot -> plotspec, phaseplot -> plotphase to avoid name conflict.

Download
1.0.0

The first formal release with complete documentation.

Download
0.12.0

- FGCalSine now supports multiple datasets with different frequencies (see function notes)

Download
0.11.0

- fix specPlot noise floor calculation
- add errHistSine input dimension check

Download
0.1.0

Download
