Deep Learning Code Generation Fundamentals

Functions, objects, and workflows that you can use to generate code for deep learning networks

You can use GPU Coder™ in tandem with the Deep Learning Toolbox™ to generate code and deploy CNN on multiple embedded platforms that use NVIDIA^® or ARM^® GPU processors. The Deep Learning Toolbox provides simple MATLAB^® commands for creating and interconnecting the layers of a deep neural network. The availability of pretrained networks and examples such as image recognition and driver assistance applications enable you to use GPU Coder for deep learning, without expert knowledge on neural networks, deep learning, or advanced computer vision algorithms.

Apps

expand all

GPU Coder

GPU Coder	Generate CUDA code from MATLAB code
GPU Environment Check	Verify and set up GPU code generation environment

Functions

expand all

Code Generation

`codegen`	Generate C/C++ code from MATLAB code
`cnncodegen`	Generate code for a deep learning network to target the ARM Mali GPU
`coder.loadDeepLearningNetwork`	Load deep learning network model
`coder.DeepLearningConfig`	Create deep learning code generation configuration objects
`analyzeNetworkForCodegen`	Analyze deep learning network for code generation (Since R2022b)
`coder.ai.enableParameterUpdate`	Enables run-time update of network parameters (Since R2025a)
`coder.regenerateDeepLearningParameters`	Regenerate files containing network learnables and states parameters (Since R2021b)
`gpucoder.installTensorRT`	Install NVIDIA TensorRT library in MATLAB (Since R2025a)

Objects

expand all

Code Configuration Objects

`coder.CuDNNConfig`	Parameters to configure deep learning code generation with the CUDA Deep Neural Network library
`coder.TensorRTConfig`	Parameters to configure deep learning code generation with the NVIDIA TensorRT library
`coder.gpuConfig`	Configuration parameters for CUDA code generation from MATLAB code by using GPU Coder
`coder.gpuEnvConfig`	Configuration object for checking the GPU code generation environment

Code Configuration Parameters

expand all

Code Generation from MATLAB

Deep learning target library	Target library for deep learning code generation
Enable auto tuning	Enable auto tuning
Data type (cuDNN)	Inference computation precision
Calibration result file path (cuDNN)	Location of calibration MAT-file
Data type (TensorRT)	Inference computation precision
Calibration data path	Image dataset location
Number of calibration batches	Number of calibration batches

Basics

Code Generation Overview

Overview of CUDA^® code generation workflow for convolutional neural networks.

Load Pretrained Networks for Code Generation

Create a dlnetwork object, or an object detector for code generation.

Supported Networks, Layers, and Classes

Networks, layers, and classes supported for code generation.

Analyze Network for Code Generation

Check code generation compatibility of a deep learning network.

Code Generation for dlarray

Use deep learning arrays in MATLAB code intended for code generation.

dlarray Limitations for Code Generation

Adhere to code generation limitations for deep learning arrays.

Analyze Performance of Code Generated for Deep Learning Networks

Analyze the performance of the generated CUDA code for deep learning networks.

Topics

Data Layout Considerations in Deep Learning
Fundamental data layout considerations for authoring example main functions.
Quantization of Deep Neural Networks
Overview of the deep learning quantization tools and workflows.
Update Network Parameters at Run Time
Update deep learning network parameters at run-time without regenerating code.
Update Network Parameters After Code Generation
Perform post code generation updates of deep learning network parameters.
Code Generation for Deep Learning Networks by Using cuDNN
Generate code for pretrained convolutional neural networks by using the cuDNN library.
Code Generation for Deep Learning Networks by Using TensorRT
Generate code for pretrained convolutional neural networks by using the TensorRT library.
Code Generation for Deep Learning Networks Targeting ARM Mali GPUs
Generate C++ code for prediction from a deep learning network targeting an ARM Mali GPU processor.
