Waveform Exploration

6G waveform exploration

The examples linked here show you how to model candidate 6G waveforms with MATLAB^®. You can:

Explore waveforms with parameters beyond the limits stipulated by NR 5G.
Perform 6G link-level simulations.
Explore the impact of hardware impairments at sub-THz carrier frequencies.
Simulate a communications link that uses orthogonal time frequency space (OTFS) modulation.

Objects

`pre6GCarrierConfig`	Extended carrier configuration parameters (Since R2024a)
`pre6GPDSCHConfig`	Extended PDSCH configuration parameters (Since R2024a)

Measure the throughput of a pre-6G link.

Measure ACPR and EVM to explore the impact of hardware impairments at sub-THz frequencies on a 6G-like waveform.

Simulate an OTFS communication link in a high-speed mobile environment.
