Tuning with Control System Tuner

Tune control systems using an interactive app

Control System Tuner lets you tune any control system architecture to meet your design goals. You can tune multiple fixed-order, fixed-structure SISO or MIMO control elements distributed over any number of feedback loops.

Control System Tuner automatically tunes the controller parameters to satisfy the must-have requirements (design constraints) and to best meet the remaining requirements (objectives). The library of tuning goals lets you capture high-level design requirements in a form suitable for fast automated tuning. Available tuning goals include standard control objectives such as reference tracking, disturbance rejection, loop shapes, closed-loop damping, and stability margins.
