NXP Support from Embedded Coder

Generate code optimized for NXP processors.


Capabilities and Features

MATLAB Coder™, Simulink Coder™, and Embedded Coder® generate ANSI/ISO C/C++ code that can be compiled and executed on NXP™ processors. Embedded Coder lets you easily configure the code generated from MATLAB® and Simulink® algorithms to control software interfaces, optimize execution performance, and minimize memory consumption.

Using NXP toolboxes based on Embedded Coder, you can generate code from your Simulink models and implement it directly on the supported processors listed below, generate processor-optimized code, perform processor-in-the-loop (PIL) tests with execution profiling, and use a full set of I/O devices and peripherals.

You can also use Embedded Coder to create your own NXP processor-specific customizations using published APIs and reference examples. For example, you can generate processor-specific (non-ANSI) optimized code.

Supported Hardware

MATLAB Coder, Simulink Coder, and Embedded Coder generate ANSI/ISO C/C++ code that can be compiled and executed on any DSP or microcontroller, including the devices listed below:

8 bit 16 bit 32 bit 64 bit
HC08 MCUs HC12, HC16 MCUs S32 Processors and MCUs QorIQ® ARM® Processors
HC05, HC11 MCUs HCS12, S12X MCUs MPC55xx/MPC56xx/MPC57xx Automotive and Industrial MCUs
RS08, S08 MCUs DSP5685x, DSP56F8xx DSCs Kinetis® ARM Cortex® MCUs
LPC9XX/80C51 MC56F8xx DSCs i.MX Application Processors
  S12 MagniV® ColdFire+®/ColdFire® MCUs
    MC56F84xxx DSCs
    MPC7xxx, MPC8xxx Power Architecture® (PowerPC®)
    MPC5xxx (Qorivva) Power Architecture Automotive MCUs
    QorIQ Processing Platforms
QorIQ Qonverge® Platform

    Vybrid® Controller Solutions
    PowerQUICC® Processors
    mobileGT® MPC51xx/52xx


LPC800/1100/1200 ARM Cortex-M0+/M0-Based MCUs
LPC1800/1700/1500/1300 ARM Cortex-M3-Based MCUs
LPC54000/4300/4000 ARM Cortex-M4 Single/Multicore-Based MCUs
LPC2900/3100/3200 ARM9™-Based MCUs
LPC2100/200/300/400 ARM7™-Based MCUs


    MAC57Dxxx ARM-Based MCUs

NXP Model-Based Design Toolbox support includes:

  • S32K: 32-Bit Automotive General Purpose Microcontrollers
  • MPC574xP: Ultra-Reliable MPC574xP MCU for Automotive and Industrial Safety Applications
  • MPC564xL: Ultra-Reliable Dual-Core 32-Bit MCU for Automotive and Industrial Applications
  • MPC567xK: Ultra-Reliable MPC567xK MCU for Automotive and Industrial Radar Applications
  • S12ZVM: S12ZVM Mixed-Signal MCU for Automotive and Industrial Motor Control Applications
  • S12ZVMB: Mixed-Signal MCU for Automotive and Industrial Motor Control Applications
  • KV1x: Kinetis KV1x-75 MHz, Entry-Level 3ph FOC / Sensorless Motor Control MCUs Based on ARM Cortex-M0+
  • KV3x: Kinetis KV3x-100–120 MHz, Advanced 3ph FOC / Sensorless Motor Control MCUs Based on ARM Cortex-M4
  • KV4x: Kinetis KV4x-168 MHz, High-Performance Motor / Power Conversion MCUs Based on ARM Cortex-M4
  • KV5x: Kinetis KV5x-240 MHz, Motor Control and Power Conversion, Ethernet, MCUs Based on ARM Cortex-M7
  • MC56F827xx: MC56F82xxx: MC56F826xx and MC56F827xx Digital Signal Controllers

NXP Vision Toolbox for MATLAB support includes:

  • S32V234: Vision Processor for Front and Surround View Camera, Machine Learning, and Sensor Fusion

Except for the FRDM-K64F and FRDM-KL25Z, MathWorks does not offer an Embedded Coder hardware support package for devices listed on this page. Third-party connection hardware and software products may exist, such as those listed above from NXP, and MathWorks Consulting Services is available to aid with hardware integrations.

NXP and various NXP products listed above are trademarks of NXP B.V. All rights reserved. © 2019 NXP B.V.


Related Hardware Support Views: Aerospace and Defense, Automotive, Communication Infrastructure, Connections Program, Consumer Electronics, C ∕ C++ Code Generation, Embedded Coder, Embedded Systems, Freescale, IEC 61508, Industrial Automation and Machinery, ISO 26262, MathWorks Supported, Medical Devices, NXP, Power Electronics Control Design, Simulink Product Family

Hardware

Required

Any NXP hardware listed above

Software

Required

  • IDE or compiler tool chain
  • RTOS (optional)

Don't see the hardware you're looking for?
